Homepage / Prodotti / Guarnizione e foglio / Guarnizione non metallica / Pure PTFE Gaskets: The Ultimate Sealing Solution for Corrosive and High-Temperature Applications

Pure PTFE Gaskets: The Ultimate Sealing Solution for Corrosive and High-Temperature Applications

Descrizione:

TOP SEALING Pure PTFE Gaskets are crafted from PTFE, meticulously formulated with additives and fillers to enhance their performance. This innovation bolsters the gaskets' wear resistance and amplifies their exceptional blend of chemical, physical, and electrical properties, ensuring a superior sealing solution for a wide range of applications.

Pure PTFE Gaskets: The Ultimate Sealing Solution for Corrosive and High-Temperature Applications

Immagine dettagliata

Dettagli del prodotto

Description Item		PTFE (Polytetrafluoroethylene)
Description Item		English	Metirc
Tensile strength		1,500-3,000psi	103-206bar
Flexural modulus		72,000psi	4964bar
Izod Impact	Notched	3.5ft-lbs/in	7KJ/m2
Heat Deflection Temperature	at 66 psi	250℉	120℃
Continuous Temperature	Maximum	500℉	260℃
Water Absorption	Immersion 24 hours	<0.01%
Coefficient of Linear Thermal Expansion		8.9in/in/ºFx10-5
Coefficient of Friction	Dynamic	0.1

Altri stili

Dati applicativi

Vantaggi

Video

Confronto Visione

Description Item	PTFE Gasket
	English	Metric
Thickness	0.06-0.2inch	1.5-5mm
Diameter	0.8-15inch	20-400mm
Temperature Resistance	600°F	315°C
Operating Pressure	3000psi	200bar
Dielectric Breakdown	406 V/mil	16 KV/mm
Volume Resistivity	1.0 x 105 ohm-cm
Creep Relaxation	30%
Compressibility	57%

Simply you can wholesale Pure PTFE Gaskets: The Ultimate Sealing Solution for Corrosive and High-Temperature Applications direct from manufacturers.

Produttore professionale

SUNPASS SEALING è un produttore leader in Sigillatura e Isolamento in Cina. Produzione e Servizio 7*24. Sunpass è un famoso marchio cinese e Pure PTFE Gaskets: The Ultimate Sealing Solution for Corrosive and High-Temperature Applications fornitori conosciuto nel mondo dal 2000.
